Optional equipment:
1) Automatic suction machine
2) Surface treatment
3) Air compressor
4) Quick screen change device
5) Automatic lifting
Main technical parameters：
|
Model |
XY-C75 |
XY-C90 |
XY-C105 |
XY-120 |
|
Materials used |
HDPE, LDPE, LLDPE |
|||
|
Maximum film folding diameter (mm) |
1500 |
2000 |
2500 |
3000 |
|
Film thickness (mm) |
0.008-0.15mm |
|||
|
Maximum extrusion volume |
120kg/h |
160kg/h |
190kg/h |
220kg/h |
|
Extrusion unit |
||||
|
gearbox |
200 |
220 |
173 |
180 |
|
Screw diameter |
φ75 |
Φ90 |
φ105 |
Φ120 |
|
Screw aspect ratio |
28:1 |
28:1 |
28:1 |
28:1 |
|
Screw material |
38 CRMOALA |
|||
|
Barrel material |
38 CRMOALA |
|||
|
temperature control |
5 |
5 |
5 |
5 |
|
Host power |
37kw |
45kw |
75kw |
90kw |
|
Die head |
||||
|
Die mouth |
Φ350 |
Φ500 |
Φ700 |
Φ900 |
|
cooling fan |
2kw |
2kw |
2kw |
2kw |
|
temperature control |
2 |
2 |
2 |
2 |
|
Rotary die |
Continuous rotation 360 degrees |
|||
|
Traction part |
||||
|
Traction roller width |
Φ160*1650 |
Φ180*2200 |
Φ180*2700 |
Φ180*3200 |
|
Lead motor power |
2.2kw |
2.2kw |
2.2kw |
2.2kw |
|
Retrieval speed |
10-60 m/min |
10-60 m/min |
10-60 m/min |
10-60 m/min |
|
Rewinding part |
||||
|
Winding method |
Friction double winding |
|||
|
Rewinding wheel width |
1600mm |
900mm |
1100mm |
1300mm |
|
Coiling power |
10N |
10N |
10N |
10N |
|
power supply |
380V, 50HZ, 3PHASE |
|||
|
Covered area |
5.2*2.8*6.0m |
6.2*3.4*8.0m |
6.2*4.0*9.0m |
6.8*4.5*10.0m |
