Features:
1. This machine is a vertical slitting machine
2. Independent master control panel makes operation more flexible and convenient.
3. The photoelectric eye used to correct the deviation of the paper is suitable for tracking the edges and colors of transparent materials.
4. The unwinding uses an air expansion shaft, automatic tension control, and magnetic powder brake for unwinding.
5. The winding adopts double camshaft and magnetic powder clutch to rewind.
6. Host frequency conversion speed regulation.
7. Equipped with waste suction device.
Main technical parameters:
|
Model |
XYQ-700B |
XYQ-1100B |
XYQ-1300B |
|
Maximum width of slitting roll |
700mm |
1100mm |
1300mm |
|
Maximum diameter of slit roll |
600mm |
600mm |
600mm |
|
Slitting roll width |
30-600mm |
30-1000mm |
30-1200mm |
|
Slitting speed |
5-160m/min |
5-160m/min |
5-160m/min |
|
Correction error |
<±0.5mm |
<±0.5mm |
<±0.5mm |
|
total power |
2.7kw |
3.5kw |
3.5kw |
|
Machine weight |
1.2T |
1.5T |
1.8T |
|
Machine appearance |
2.0*1.1*1.4m |
2.4*1.1*1.4m |
2.6*1.1*1.4m |
